CDA 110

Product Overview

CDA 110 is pure copper and often used for high temperature brazing applications. It is primarily used for brazing ferrous or nickel based alloys in a furnace for industries such as automotive or electrical or where oxygen free grades of copper such as CDA 101 or 102 are not required. Due to its extremely fluid nature, CDA 110 should only be used where tight clearances can be maintained.
  • Economical
  • Fast flow

    • Typical Industry Applications:

    Fuel rails, manifolds

    Talk to an Expert

    Product Details

    Name:CDA 110

    Nominal Composition:Copper 99.90

    Liquidus:1981 °F °, 1083 °C

    Solidus:1981 °F °, 1083 °C

    Max Recommended Brazing Temperature:2150 °F, 1177 °C

    Heating Methods:Controlled Atmosphere, Vacuum

    Industry Specifications:

    • AMS: 3430 Type 2 (Paste)
    • AMS: 4500 (Strip)
    • AMS: 4740 (Powder)
    • AWS: BCu-1b
    • ISO 17672: Cu 110

    Common Industries

    .

    Automotive

    Lucas Milhaupt helps automotive manufacturers prepare for the next wave of automotive technology with innovative brazing alloys and process improvements.
